Cov tswv yim ntawm TD556S 2 theem stepper lub cev muaj zog tsav
Khoom Nta:
1.Voltage: 24V ~ 50VDC, siab tam sim no 5.6A
2.Txhais rau kev sib nqus sib txuas tiv thaiv vector resonance resistance algorithm thiab hluav taws xob hluav taws xob damping qis kev co lub suab qis
3.Auto paub txog cov cim lub cev muaj zog thiab pib sib txuas tswj cov roj thaum fais fab tuag
4.Build-in micro-step segmentation algorithm, kom ua tiav qib micro-kauj ruam hais kom ua kom tiav, qib siab ua haujlwm siab ua haujlwm.
5.Txais ntau qhov sib txawv thiab ib leeg-kawg PUL / DIR hais kom ua
6.Pulse, kev taw qhia, pab kom lub teeb liab chaw nres nkoj hluav taws xob qib tau tshaj 4.5V ~ 28VDC, tsis tas yuav txuas cov sab nraud resistor
7.Txhob muaj qhov zoo, qhov tsis zoo thiab lub cev muaj zog thaum pib ntawm qhov chaw nres nkoj serial
8.Control command Max mem tes zaus yog 500KHz (Default yog 200KHz)
9. Txhawb 15 lub zog micro-kauj ruam tus nqi teeb tsa, txhawm rau 200 ~ 51200 micro-kauj ruam los ntawm Serial chaw nres nkoj
10.Txais cov chaw nres nkoj RS-232 lossis RS-485, tuaj yeem tsim lossis tswj tsav tsis
11. tuaj yeem kho mus rau 0 ~ 5V analogy ceev muaj nuj nqi
12.Reliable, teeb liab chaw nres nkoj yog qhov cais tawm tsis pub muaj
13. Tshaj-voltage, dhau-tam sim no, qis tiv thaiv kev tiv thaiv
Daim Ntawv Thov Khoom:
Nws tuaj yeem siv ntau hom tshuab, xws li CNC mills, laser cutters, laser npav, siab precision XY rooj, tshuab ntaus cim, khoom siv kho mob, 3D tshuab luam ntawv, twj siv hluav taws xob, ntim tshuab, neeg hlau thiab lwm yam. Nws cov yam ntxwv tshwj xeeb ua rau TD556S qhov kev daws teeb meem zoo rau kev siv uas yuav tsum muaj lub suab qis thiab kev ua haujlwm siab ceev.
DIP Cov Lus Qhia
TD series tsav siv 8 DIP los tsim micro-kauj ruam, khiav tam sim no thiab ib nrab / tag nrho tam sim no, hauv qab no yog qhov nthuav dav ntawm qauv TD556S:
Tam sim no Teem Ib Nrab / Tas-Tam Sim No Micro-kauj ruam kev teeb tsa
KHOOM TAM SIM NO QHOV CHAW:
Ncov Tam Sim No | Siv tau tam sim no | SW1 | SW2 | SW3 |
Lub neej ntawd | 1.0A (RMS) | TAWM | TAWM | TAWM |
2.1A | 1.5A | ON | TAWM | TAWM |
2.7A | 1.9A | TAWM | ON | TAWM |
3.2A | 2.3A | ON | ON | TAWM |
3.8A | 2.7A | TAWM | TAWM | ON |
4.3A | 3.1A | ON | TAWM | ON |
4.9A | 3.5A | TAWM | ON | ON |
5.6A | 4.0A | ON | ON | ON |
Micro-kauj ruam kev teeb tsa:
Kauj Ruam / R | SW5 | SW6 | SW7 | SW8 |
Vim (200) | ON | ON | ON | ON |
400 | TAWM | ON | ON | ON |
800 | ON | TAWM | ON | ON |
1600 | TAWM | TAWM | ON | ON |
3200 | ON | ON | TAWM | ON |
6400 | TAWM | ON | TAWM | ON |
12800 | ON | TAWM | TAWM | ON |
25600 | TAWM | TAWM | TAWM | ON |
1000 | ON | ON | ON | TAWM |
Xyoo 2000 | TAWM | ON | ON | TAWM |
4000 | ON | TAWM | ON | TAWM |
5000 | TAWM | TAWM | ON | TAWM |
8000 | ON | ON | TAWM | TAWM |
10000 | TAWM | ON | TAWM | TAWM |
20000 | ON | TAWM | TAWM | TAWM |
25000 | TAWM | TAWM | TAWM | TAWM |
Kev Xa Khoom Thiab Them Nyiaj:
Peb lub tuam txhab thov rau ntau txoj kev them nyiaj, xws li T / T, L / C; rau qee tus yuav me me, peb lees txais Paypal, Western Union. Peb tuaj yeem npaj nthuav qhia, huab cua thiab xa nkoj hiav txwv, peb muaj cov kws tshaj lij los nrog logistic.Qhov nqe lus peb tuaj yeem ua EXW, FOB, CFR, CIF, DDU thiab lwm yam.
Cim npe nrov: 2 theem stepper tsav lub cev muaj zog 5.6a tam sim no, chaw tsim tshuaj paus, tsum, hoobkas
